-- Innovations in Medical Textiles
Hospital Fabrics & Tracks
Healthcare-grade hospital curtains & track systems engineered for patient privacy, infection control, and long-term performance in critical care environments.
- BS 5867 Fire Retardant
- ASTM Anti-Microbial
- AATCC Anti-Fungal
- IS-390 Water Repellant
100%
Polyester
Medical Grade
Trusted By
- Fortis Hospitals
- ADIVA
- Rockland Hospitals
- Venkateshwar Hospital
- ILBS
- Neo Hospital
Site-to-Site Custom
Measurement & Installation
• Track & Hardware
Built for Healthcare
Environments
Medevice by Vista Furnishings Pvt. Ltd. delivers precision-engineered hospital curtain and track systems that meet the stringent demands of modern healthcare facilities.
Infection Control Certified
Anti-microbial and anti-fungal properties tested to ASTM E 2149-10 and AATCC Method 30 standards — actively reducing pathogen spread between patients.
Long Functional Life
High wash durability with 100% polyester construction ensures curtains maintain their protective properties through repeated industrial laundering cycles.
Precision Track System
Extruded aluminium alloy 6063-T6 tracks with wheel-type roller runners for smooth, noiseless operation — critical in quiet care environments.
• Fabric Details
Medical-Grade Fabric Specifications
Every curtain is manufactured from 100% polyester with multiple layers of protection tested against fire, water, oil, microbial growth, and fungal contamination.
- Key Fabric Properties
Full Curtain Dimension
4 × 7 feet
Mesh Dimension
1.5 feet
Fabric Composition
100% Polyester
Water Repellant Test
Spray Test IS-390-1975
Fire Retardant Test
BS 5867 Part-II, 5B 2008
Oil Repellency Test
AATCC 118
Anti-Microbial Test
ASTM: E 2149-10 Method
Anti-Fungal Test
AATCC Test Method 30; III 2004
Water Repellant
IS-390-1975 Spray Test
Fire Retardant
BS 5867 Part-II, 5B 2008
Oil Repellency
AATCC 118
Anti-Microbial
ASTM: E 2149-10 Method
Anti-Fungal
AATCC Method 30; III 2004
Anti-Odour
Clinical Environment Safe
High Wash Durability — Helps Avoid Secondary Infections
IS-390-1975 Spray Test
• Available Shades
Choose Your Colour
Available in three classic healthcare shades — clean, calming, and suitable for all ward and clinical environments. Contact us for shade selection assistance.
White
Clean & clinical
Grey
Neutral & calming
Blue
Therapeutic & fresh
White
Clean & clinical
Grey
Neutral & calming
Blue
Therapeutic & fresh
Photographs are for reference only. Please contact us for actual shade card selection.
• Track & Hardware
Precision Aluminium
Track System
Extruded aluminium alloy 6063-T6 track with corrosion-resistant white powder coating — engineered for smooth, noiseless movement and longer functional life.
Material
Aluminium Alloy 6063-T6 White Powder Coated
Dimensions
28 × 20 × 1.6mm One piece, surface mounted
Curved Track
Factory-fabricated Up to 12" radius bends
Runner
Plastic HD, Deralin Wheel-type roller runner
Roof Suspenders
M.S. 12mm dia. Upper plate ≥50mm, powder coated
Material
MS splices, end caps ABS plastic brackets
- Key Fabric Properties
- Details
Track Material
Extruded Aluminium Alloy 6063-T6 with corrosion resistance & standard white powder coating.28mm×20mm×1.6mm wall thickness, one piece, surface mounted.
Curved Track
Factory-fabricated up to 12 inch radius bends
Track Thickness
15 mm side & 3.3 mm top
Track Height
25 to 28 mm
Track Width
20 to 22 mm
Runner Material
Plastic HD, Deralin
Runner Type
Wheel type roller runner
Track Roof Suspenders
Made of M.S., 12mm diameter. Upper circular plate M.S., min 50mm diameter, white powder coated, fixed with ceiling anchors, bolts & screws.
Curtain Removal Point
Made of SS or high-density plastic for simple loading & unloading of curtains
Hooks
HD Plastic, flexible material
• Applications
Where Medevice Is Installed
Designed for demanding healthcare environments — wherever patient privacy and infection control are non-negotiable.
ICU & Critical Care
Infection-controlled privacy screening for intensive care unit bays and critical monitoring areas.
General Wards
Patient bay separators in multi-bed wards — providing dignity and reducing cross-contamination.
OPD & Examination
Quick-slide track systems for outpatient examination rooms and clinical consultation spaces.
Private Rooms
Premium curved and straight track systems for private hospital rooms and suites.
